YCY-115FA3 Card laminating machine

Card laminating machineYCY-115FA3 350X500 Laminator YCY-115FA3 is designed to laminate a variety of personalized cards or for small-scale card production. Characterized as hydraulic pressing, electric heating, water-cool, single tower and normal electric control, the whole machine structure is well compact and rigid. The heating temperature and the cool or heat pressure are controlled automatically with easy operation. The hydraulic system applies the imported parts. The circulating water system is equipped. Technical Parameters 3 daylights2 daylightsOne daylightMaterial applicable PVC or other plastics PVC or other plastics PVC or other plastics Plate layout 3X8 3X8 3X8 Plate number 4 each for both cool and heat 3 each for both cool and heat 2 each for both cool and heat Plate size 350X500 mm 350X500 mm 350X500 mm Daylight 48mm 48mm 48mm Material layersMAX 15 layers 15 layers 15 layers Work pressure 2 15MPa adjustable 2 15MPa adjustable 2 15MPa adjustable Pressure precision +/-1.0MPa +/-1.0MPa +/-1.0MPa Heat temperature ≤170 ≤170 ≤170 Temp. precision +/-1.5 +/-1.5 +/-1.5 Cylinder travel 320mm 320mm 320mm Oil tank volume 50 L 50 L 50 L Power supply AC220V 50/60Hz 3 wires single phase AC220V 50/60Hz 3 wires single phase AC220V 50/60Hz 3 wires single phase Power 11.1kW 8.7kW 6.3kW Productivity 2700 cards/hour 1800 cards/hour 900 cards/hour Dimension L800XW700XH1750mm L800XW700XH1580mm L800XW700XH1410mm Weight Approx. 1400 kg Approx. 1300 kg Approx. 1200 kg
